STM series 1.5 inch small diameter submersible pump

FOB Reference Price:Get Latest Price
$40.00 - $50.00 / Pieces | 100 Piece/Pieces (Min. Order)
Horsepower:
0.5hp to 10hp
Maximum Flow Rate:
0 m3/h to 8.4 m3/h
Report Suspicious Activity
Overview
Quick Details
Place of Origin:
Zhejiang, China
Brand Name:
BAQIU
Model Number:
1.5STM15/22
Structure:
Single-stage Pump
Usage:
Water
Application:
Water
Power:
Electric
Fuel:
Electric
Pressure:
High Pressure
Theory:
Centrifugal Pump
Standard or Nonstandard:
Standard
Type:
Watering
Warranty:
One Year
Motor:
100% Copper Wire
Voltage:
220V
Certificate:
CE Certificate
Impeller:
PPO/Stainless Steel
Diffuser:
Thermoplastic resin PPO
Product name:
STM series 1.5 inch small diameter submersible pump
Supply Ability
Supply Ability:
20000 Piece/Pieces per Month
Packaging & Delivery
Packaging Details
Export color cartons
STM series 1.5 inch small diameter submersible pump
Port
NingBo Port

STM series 1.5 inch small diameter submersible pump

Fields of Application

*For water supply from wells or reservoir

*For domestic use,for civil and industrial applications

*For garden use and irrigation

Suitable fluids

Clear,free from solid or abrasive substances,

Chemically natural and close to the characteristics of water

Performance

*Speed rang:2900rpm

*Fluid temperature range:-10℃-40℃

*Max.Working pressure:40 bar

*Ambient Temperature Permissible up to

  40℃

  Motor

*Degree of protection:IP68

*Insulation class:B

*Construction Materials

*Casing both of pump and motor,pump shaft:stainless steel AISI304

*Outlet and Inlet:bronze

*Impeller and diffuser,non-return valve: thermoplastic resin PPO










Q:Are you a factory or a trading company?

A: Yes,we are water pump manufacturer.



Q:What is your MOQ of this model ?

A: MOQ are 100PCS,can offer trial sample order is also OK.



Q: What is the payment terms of our factory?

A: 30%T/T ,Balance against the copy of bill of lading.



Q: How many days for 1container production?

A: 30days after receiving deposit,40days in very busy season.
